Custom Punch Dies — Engineered for Excellence
Made to Drawing |One Piece MOQ |Free Material Selection Guidance
We specialize in manufacturing high-precision Punch Dies using advanced technologies including CNC machining, EDM, grinding, polishing, and wear-resistant surface treatments. Our punch dies are tailored to meet the demanding needs of various industries such as Stamping, Injection Molding, Battery, Ammunition, Medical, Dental, Pharmaceutical, Biotech, and Electronics.
Whether you need prototypes, small batches, or mass production, we can deliver. We manufacture punch dies in sizes ranging from 0.004” to 1.25” in diameter, and up to 12” in length, with tolerances as tight as 0.0001” and surface finishes as fine as 4 RMS.
Pain Points
Problems we can solve for you
What if there is no drawing?
Provide reverse modeling + dimension restoration services
No material selected?
Provide material recommendations and hardness recommendations
The finished product is inconsistent with the sample?
Sample first + three coordinate detection
Worry about quality?
Precision cnc+ grinder + detection + life test
Whether similar parts can be made?
We support the processing and customization of a full range of mold parts and components, and supporting shipment
Factory strength？
Factory shooting + video factory inspection + transparent display of customer cases
Punch Die Gallery
Product characteristics:
| Material selection | SKD11 / D2 / DC53 / ASP23 / Carbide / HSS |
| Processing equipment | CNC + grinder + EDM |
| Surface treatment | Nitriding, polishing, PVD coating (tin, TiCN) |
| Tolerance control | Within ± 0.005mm (according to drawing requirements) |
| Mold cavity structure | Single hole, multi hole, special shape, ladder, positioning groove |
| Processing method | Customized according to drawings or samples, supporting the delivery of supporting punch / mold base |
| Application | Precision stamping die, compound die, continuous die, electronic component die, automobile stamping parts, etc |
- Core Pins
- Mold Pins & Bushings
- Ejector Pins
- Perforating Pins
- Punch Blanks
- Headless Pins
- Stamping Punches
- Piercing Punches
- Hole Punches
- Metalworking Punches
- Button Dies
- Tungsten Carbide Punches
- Aircraft Pins
- Clevis Pins (Stainless Steel)
- Machined Pins
- Grooved Pins
- Metric Pins
- Shouldered Pins
- Furniture fittings
- Bronze Pins
- Guide Bushing
- Gardening tool handles
- Sunglasses frames
- Guide Post
The customization process of punch die
Demand confirmation
· Material (recommended according to the use scenario: wear resistance, high temperature resistance or corrosion resistance)
· Tolerance requirements
· Operating environment (stamping speed, die structure)
· Whether surface treatment is required
Technical evaluation and proofing
Our engineering team uses cad/ug for design, coordinates with the coordinate measuring instrument (CMM) for size calibration, and can provide real photos of samples or send physical objects.
10,000 cycles
Zero wear
100,000 times
No cracks after punching
5xLonger life
Cryo-treatment
30%+
Hardness boost
3,000+
Industry clients
Quote Request Checklist
Material Specifications
Tolerance Requirements
Surface Treatment
Application Scenario
Drawing Availability (If none, describe)
The more details you share, the faster and more precise your quote will be! Looking forwarded to future cooperation.
Request a Quote
Application cases
Linda Smith
The customer only provides the damaged stamping die in kind. Through our reverse design + sample delivery, only one proofing, that is, 100% reduction of the die cavity.
Provide the combined die with complex drawing structure (including locating pin hole + multi-level stepped die cavity), and our cnc+ grinder will finish the fine matching processing, with the delivery date 3 days ahead of schedule.
